Hubble Lithium AM-10 200Ah 10kWh 51.2V Battery
Hubble Lithium AM-10 200Ah 10kWh 51.2V Battery - Image 2
Sold out!

Hubble Lithium AM-10 200Ah 10kWh 51.2V Battery

Availability:

Out of stock with Supplier & Manufacturer ETA is 4-8 Weeks, as soon as the stock is available the system will be updated. If needed you can place backorder with our sales team to get stock when is available. Below you can click the button to request quotation or ask to be emailed when stock is available.

R34799.00 R53699.00

Sold out!

Email when stock available

Frequently Bought Together

Hubble Lithium AM-10 200Ah 10kWh 51.2V Battery+Canadian Solar 620W TopBiHiKU6 Super High Power N-type TopCon module with EVO2 and F30 Frame+Sunsynk 12kW Three Phase Hybrid PV Inverter 48v + Wifi Dongle
Price for all:   R76687.00

Hubble Lithium’s AM-10 model is a low voltage (51V), 10kWh battery made up of superior prismatic lithium-ion cells. These battery cells have more energy density and a longer cycle life compared to standard lithium cells.

Features

  • Low self discharge

  • High cycle and service life

  • Easy wall mount or shelf rack installation

  • Excellent high temperature performance

  • 1C High performance lithium battery

  • Advanced BMS with current limiting function

  • Compatible with most inverters and chargers

  • High energy density and conversion efficiency

  • Complete with integrated Battery Management System

  • Hubble Cloudlink integration ready for cloud monitoring

  • Heavy duty side handles for easy handling and mounting on the wall

  • Built in protection for over-charge, over-discharge & over-temperature

  • CAN Bus fully integrates and communicates with leading Inverter brands

Hubble AM-10 Data SheetHubble Energy AM-10 Warranty V3

SKU: AM-10 Category:
Weight 89 kg
Dimensions 673 × 618 × 193 mm

  • Rated Capacity (5HR): 200Ah

  • Nominal Voltage: 51.2V

  • Design Capacity: 10KWH

  • Equalized Charge Voltage: 55.2V

  • Max. Continuous Charging Current: 150A

  • Max. Continuous Discharging Current: 150A

  • C Rating: 1C

  • Weight: Approx. 89kg

  • Monitoring: Cloudlink

  • Parallel: Parrallel connection up to 8 packs with full communications

  • Dimensions (WxDxH): 673mm x 618mm 193mm

  • Ports: CAN-bus, Battery Link Ports

  • Cells: Prismatic LiFePO4

  • Design Life: ± 15 Years

  • Cycle Life: UNLIMITED CYCLES WITHIN THE HUBBLE LITHIUM 10 YEAR WARRANTY. (Ts & Cs Apply)

  • Certification: CE IEC UN38.3

  • Outer Package Material: White Bake Lacquer Steel Case

  • Operating Temperature

  • Charging: -10°C to +50 °C

  • Humidity: 15% to 75%

  • Storage: 10°C to +50°C

  • Protection: Electronic Circuit Breaker, BMS Voltage Protection, Current Limiting
