Freedom Won Lite Commercial 230/184 High Voltage+ Battery

1. The maximum values given apply to both charge and discharge. For systems requiring more power, two or more batteries must be installed in parallel. Max current duration 5min every 10min. 1.5 x Max overload can be handled for 5 seconds. Current limits rated for 10°C to 25°C battery temperature. De-rating will apply outside this temperature range.
2. Excluding protrusions.
3. Fly Leads 4.0m long as standard, power cable Red = Positive, Black = Negative, conductors in table refer to one electrode i.e. per positive and negative connections. Up to 8m long available at extra cost (must be specified in order). Note that the fly leads exit the battery on the right-hand side near the floor on all the LiTE Commercial HV and HV+ models. This is to suit the bottom entry of the floor standing ATESS inverters. A cable trench is recommended for routing this cable along with all the other cables going to and from the inverter (a cable tray is an alternative).
4. Charging below 0°C not permitted. Extended time above 35°C not recommended for optimal battery life.
5. See Freedom Won Warranty document for further detail.

Key Features:

• Vast Energy Storage: 230 kWh total capacity to meet all your commercial energy demands.
• High Efficiency: 184 kWh usable at 80% DoD, for continuous, reliable power.
• Robust and Reliable: Over 16 years of expected service life, with a 10-year warranty for peace of mind.

Ideal for industrial operations, data centers, and other high-energy consuming businesses looking for a dependable and powerful energy storage solution.
